Description：Semi-automatic Cartridge Dry Tester (Workshop)

Tel:13414188372

Consult Now

Introduction

1、Applicable Products

Pressure Balancing Valves Diverter Cartridges Ceramic Cartridges Quarter-Turn Cartridges

2、Equipment Functions:

(1) Air tightness test for cartridges;

(2) Automatic switching of different gears (cold water / hot water, open / close status);

(3) Quick model changeover.

3、Applicable Standards：

Standard	Relevant Content
GB 18145-2014 (Chinese National Standard)	① 7.6.2 Tightness Performance ② 8.6.2 Tightness Performance Test
BS EN 817:2008 (British Standard)	① 8.3 Upstream Tightness with Cartridge Closed ② 8.4 Downstream Tightness with Cartridge Open ③ 8.7 Cartridge Tightness Performance (Cold & Hot Water Cross Flow)
BS EN 200:2008 (British Standard)	① 8.2 Cartridge Tightness Performance ② 8.3 Upstream & Downstream Tightness Test for Cartridge

4、Basic Parameters of Standard Machine：

Equipment Dimension	L1000mmW740mmH1900mm
Recommended Air Tightness Test Pressure Range	0.3Mpa~0.6Mpa
Air Tightness Test Accuracy	1.5CC/Min
Number of Stations	6
Number of Test Chambers	2 pcs per station
Power	1KW
Voltage	220V~
Average Testing Efficiency	Quarter-turn Cartridge: 5 s/pc Flat-foot Cartridge: 15 s/pc
